Poly Studio X32 — all-in-one video bar for huddle rooms and small meeting rooms with native Microsoft Teams, Zoom and Google Meet, powered over PoE++.

Room up to 4.6 × 3.0 m

20 MP camera · 132° diagonal

Microphone pickup up to 4.5 m

Teams · Zoom · Google Meet

PoE++ powered, no power supply included

Poly Studio X32 ordering variant in our range
Order code	Contents	Note
A3SV5AA#ABB	video bar, cables and display mounting clamp, without a power supply (this product)	power comes from PoE++, from a switch or an injector

Key features

All-in-one video bar: camera, microphones and speakers in a single unit
20 MP camera, 132° diagonal field of view, 5x digital zoom
Poly DirectorAI smart camera: people framing, group framing and speaker framing
Four MEMS microphones with pickup range up to 4.5 m
Native Microsoft Teams, Zoom and Google Meet apps on the device
Powered over a single network cable, PoE++ to IEEE 802.3bt, class 6

Description

A huddle room without a cabinet full of hardware

Poly Studio X32 is intended for huddle rooms and small meeting rooms, that is spaces up to roughly 4.6 × 3.0 metres. Camera, microphones and speakers sit in one unit and meetings run directly on the device, with no computer in the room. Installation means connecting a display and the network and configuring the platform, the room account and the controls.

One cable into the room

Studio X32 is powered over PoE++, so the video bar needs no power supply of its own and a single network cable is enough. Power for the display and other components is handled separately. That is a fundamental difference from the larger models in the range, which have their own AC adapter. The exact standard and class required are stated in Limits and in the atlantis note.

Everyone is seen and heard

The 20-megapixel camera covers a short room where participants sit close, thanks to a 132° diagonal field of view. Poly DirectorAI provides automatic framing of individuals (people framing) and of the whole group (group framing) as well as active speaker tracking (speaker framing). Four MEMS microphones pick up voices at a range of up to 4.5 metres, which matches the recommended room size.

Teams, Zoom or Google Meet, as the customer chooses

The device runs native apps for Microsoft Teams, Zoom and Google Meet. The platform decision is therefore not a hardware decision: the platform is chosen during configuration and can later be changed in settings. In Poly App mode, standards-based SIP and H.323 up to 6 Mbps are also available for connecting to video conferencing infrastructure. Content can be connected by cable over the HDMI input, and over USB the video bar serves as camera and audio for a connected laptop.

Strengths and limits

Strengths

Power and data over one cable, the video bar needs no socket of its own and no building work
Three native platforms on one device, the platform decision can wait
Two HDMI 2.0 outputs for two displays
Display mounting clamp and cables included in the box

Limits worth telling the customer

No power supply is included. The device requires PoE++ to IEEE 802.3bt, class 6, from a switch or an injector. Standard PoE and PoE+ are not sufficient.
The recommended room size is up to 4.6 × 3.0 m and the microphones reach 4.5 m. A larger meeting room needs Studio X52 or X72.
The camera has fixed focus and digital zoom, not optical.
The standard manufacturer warranty on this model is one year.

⚑ atlantis note

Power

The manufacturer's official name for this code is "No Power Supply". Power has to be resolved in the network design, that is a switch with PoE++ to IEEE 802.3bt or an injector. We are happy to confirm a suitable injector from our range for the specific installation, as none is included with this code.

Region

The #ABB suffix is the European variant. Ordering #ABA is the most common mistake with HP products and the two are not interchangeable.

Mounting

The box contains a display mounting clamp. The wall and VESA mounting kit (875L6AA) and the table stand (875L5AA) are not included and are ordered separately.

Controls

For native Teams Rooms or Zoom Rooms mode allow for a touch controller, that is Poly TC10 (875K5AA black, 875J5AA#AC3 white). It is not in the video bar box.

Room fit

Recommended room parameters
Recommended room size	up to 4.6 × 3.0 m (15 × 10 ft)
Microphone pickup range	4.5 m
Number of displays	2, HDMI 2.0 outputs
Typical deployment	huddle room, small meeting room, manager's office

Good fit

A huddle room or small meeting room up to 4.6 × 3.0 m, a single platform (Teams, Zoom or Google Meet), a network with PoE++ and a requirement for a clean installation with no PC and no socket for the video bar.

Check the design

Availability of PoE++ to IEEE 802.3bt on the target port, a room deeper than 4.5 m, hard acoustics, backlight from a window. We are happy to review it.

Consider another model

For a standard meeting room choose Studio X52, for a large room Studio X72 with dual cameras. See the range table below.

Modes of use and platforms

Recommended for a permanent room

Native room system

Meetings run directly on the device, with no computer in the room. The platform is chosen during configuration and can later be changed in settings.

Microsoft Teams

Zoom

Google Meet

For guests and other platforms

USB mode (BYOD)

The video bar appears as a USB camera and audio device for a connected laptop, so a guest uses the application they have on their own device.

Connected over USB

Connecting to infrastructure

Standards-based protocols

Calls over SIP and H.323 up to 6 Mbps in Poly App mode, for connecting to video conferencing infrastructure. We are happy to review the design.

SIP

H.323 up to 6 Mbps

The device always runs in one of these modes, they do not run side by side. Changing the native platform is a configuration step in the device settings, not switching during a meeting.

Connectivity, network and security

The parameters the customer's IT and security teams ask about most often when approving a deployment. The figures match the HP technical specification for order code A3SV5AA.

Poly Studio X32 connectivity, network and security
Interfaces	1× HDMI input 1.4 (video and audio), 2× HDMI output 2.0 (video), 1× USB-C 5 Gbps, 2× USB-A 5 Gbps, 1× RJ-45
Network	1× 10/100/1G Ethernet, Auto-MDIX, IPv4 and IPv6, web proxy basic, digest and NTLM, SCEP, LPR and dynamic bandwidth allocation
Wi-Fi and Bluetooth	Wi-Fi 802.11a/b/g/n/ac/ax (MIMO), Bluetooth 5.0
Media encryption	AES-128 and AES-256 for H.323 and SIP, H.235.6 support
Management security	authenticated access to admin menus, web interface and APIs, password policy, security profiles, secure defaults, remote logging with TLS support, Active Directory external authentication
Power	PoE++ injector or switch, IEEE 802.3bt, class 6. No power supply is included.
Operating environment	0 to 40 °C, humidity 15 to 80 %
Central management	Poly Lens (cloud): inventory, monitoring, diagnostics, bulk updates

Poly Studio X32 video and audio
Camera resolution	20 MP
Field of view	132° diagonal
Zoom and focus	5x digital zoom, fixed focus
Frame rate	6.25 to 30 fps, up to 4K resolution at 15 fps in call
Smart camera	Poly DirectorAI: people framing, group framing, speaker framing
Microphones	4× MEMS, pickup up to 4.5 m, sensitivity -26 dB FS/Pa, signal-to-noise ratio 63 dB
Speakers	sensitivity 77 dB (1 W / 1 m), bandwidth 100 Hz to 20 kHz
Lens cover	attachable
Dimensions and weight	576.8 × 66.1 × 74.8 mm, 1140 g

What's in the box

In the box

Poly Studio X32
Display mounting clamp
HDMI cable
Ethernet cable
Privacy cover

Not included

Power supply. The device is powered over PoE++ from a switch or an injector.
Poly TC10 touch controller (875K5AA, 875J5AA#AC3)
Wall and VESA mounting kit 875L6AA
Table stand 875L5AA
Poly+ Partner service programme

Order with it

PoE++ powerper network design

A switch or injector to IEEE 802.3bt, class 6. We are happy to confirm a suitable solution for the specific installation.

Poly TC10 touch controller875K5AA / 875J5AA#AC3

For native Teams Rooms or Zoom Rooms mode.

Wall and VESA mounting875L6AA

The box contains only the display clamp.

Table stand875L5AA

For placement on a table or a cabinet.

HDMI cable of the right lengthper installation

Depending on the distance to the display.

Variants and products in the range

Poly Studio X range comparison
Model	Recommended room	Camera	Microphone pickup	Power
Current generation
Poly Studio X32 ◂ this product	up to 4.6 × 3.0 m	20 MP, 132° dia.	4.5 m	PoE++
Poly Studio X52	up to 6.1 × 4.6 m	20 MP, 110° dia.	6.09 m	AC adapter
Poly Studio X72	up to 8.5 × 4.6 m	2× 20 MP, 140° and 78° dia.	7.6 m	AC adapter
Previous generation (available as an alternative)
Poly Studio X70	up to 9.1 × 6.1 m	2× 20 MP, 140° and 78° dia.	7.6 m	AC adapter

What to check before ordering and installing

Power: PoE++ to IEEE 802.3bt, class 6, on the target port, or an injector. Verify during design, not at installation.
Room: dimensions and depth against the 4.5 m microphone pickup, acoustics and backlight from windows behind participants
Platform: Teams Rooms, Zoom Rooms or Google Meet, room account, licences and tenant rules
Displays and mounting: one or two displays, HDMI cables of the right length, the display clamp from the box or kit 875L6AA or table stand 875L5AA
Controls and network: the Poly TC10 touch controller and its PoE, VLAN, firewall and proxy, DNS and NTP, certificates and the customer's rules for AV traffic
Operation: current firmware, registration in Poly Lens, the Poly+ Partner programme, training and an acceptance test

The atlantis team will help with every point. From validating the room and power design through pre-configuration to installation, integration and on-site training.

Licensing and services

Poly Lens cloud management: remote inventory, monitoring, diagnostics and bulk software updates
Poly+ Partner: local support in Czech or English from an experienced certified team, by phone, chat, web and video call, expedited device replacement with the manufacturer shipping the replacement part on the next business day and paying the freight, all under the programme terms and for its whole term, so care can continue after the manufacturer warranty ends
atlantis installation and configuration: delivery to site, mounting, individual configuration for the customer and the specific room, connection to the communication platform, network integration, interfacing with third-party components, user training, handover documentation and further services on request

Warranty

Standard one-year limited HP Poly warranty. Extended support with expedited device replacement is provided by the Poly+ Partner programme.

Frequently asked questions

Is a power supply included?

No. In this ordering variant Poly Studio X32 is powered over PoE++ to IEEE 802.3bt, class 6, that is from a switch or an injector; standard PoE and PoE+ are not enough. The manufacturer's official name for the code is "No Power Supply". Availability has to be verified on the specific port during design.

Do I need a separate PC with Studio X32?

No, in native mode Poly Studio X32 needs no separate PC. The Teams, Zoom and Google Meet apps run on the device itself. A laptop is only needed in USB mode.

What room size does X32 suit?

Designed for a room of 15 × 10 ft, that is roughly 4.6 × 3.0 metres. The microphones reach 4.5 m. For a standard meeting room choose Studio X52, for a larger room Studio X72.

Is a mount included?

The Poly Studio X32 box contains a display mounting clamp. The wall and VESA kit (875L6AA) and the table stand (875L5AA) are not included.
