Poly Rove B4 — a DECT base station for multicell deployment. The system scales to 254 stations and 1,000 handsets with a capacity of 2,000 simultaneous calls. It is PoE powered and has no adapter in the box.

Multicell, up to 254 stations

Up to 8 calls per station, 2,000 per system

Up to 1,000 handsets per system

Up to three R8 repeaters per station

DECT band 1880 to 1900 MHz

PoE powered, no adapter in the box

Poly Rove system infrastructure in our offering
Order code	Product	Type	Deployment	Simultaneous calls	Power
8J8W3AA#ABB	Rove B2	base station	single or dual cell	up to 10, single cell	adapter in the box
8J8W4AA#ABB	Rove B4 (this product)	base station	multicell, up to 254 stations	up to 8 per station, 2,000 per system	PoE, adapter not in the box
84H79AA#ABB	Rove R8	repeater	extends base station coverage	no capacity of its own	adapter in the box

The base station is ordered together with handsets. We offer two, the Rove 30 (84H76AA#ABB) and the Rove 40 (84H77AA#ABB) with Bluetooth. Handsets are not in the base station box and the base station is not in a handset box.

Key features

Multicell operation, the system scales to 254 base stations
Up to 1,000 handsets across the system
Up to 8 simultaneous calls per station and up to 2,000 across the system
Range of up to 50 metres indoors, with repeaters up to 300 metres outdoors
Up to three Poly Rove R8 repeaters per base station
DECT band 1880 to 1900 MHz for Europe and the Asia Pacific region
A gigabit RJ-45 port and PoE power, the adapter being optional
DECT end-to-end encryption and DECT security certification

Description

The core of the system, not an accessory

The Rove B2 is the heart of a DECT system. Handsets register to it, it holds the calls and it is what connects to the PBX or cloud service. System capacity is therefore not set by the number of handsets but by the choice of base station. The B4 is intended for multicell deployment, that is a campus, a multistorey building or a large warehouse. For one floor or a smaller site the B2 is enough.

System capacity, not station capacity

For the B4 HP quotes up to 8 simultaneous calls per station and up to 2,000 across the system, which holds up to 254 stations and 1,000 handsets. A single B4 station therefore carries fewer calls than a B2, but the system is built from many stations. The number of stations is not determined by coverage alone, but also by how many calls have to run at once in a given zone.

Coverage is extended by repeaters, not by another base station

The range of one station is up to 50 metres indoors. Coverage comes from two sources, from further B4 stations and from Rove R8 repeaters, of which HP allows up to three per B4 station. A station needs a data socket with PoE, a repeater only a mains one. With repeaters HP quotes up to 300 metres outdoors. Design the coverage in advance, adding to it later works out more expensive.

Strengths and limits

Strengths

A multicell system of up to 254 stations and 1,000 handsets, capacity growing with each added station
PoE power, so the station needs no mains socket where it is mounted
A gigabit RJ-45 port and an Ethernet cable in the box
DECT end-to-end encryption and DECT security certification

Limits and what to tell the customer

Handsets are not in the box. The Rove 30 and Rove 40 are ordered separately.
The power adapter is not in the box. The station expects PoE, the adapter is optional, code 85W97AA#ABB.
A single station carries only 8 simultaneous calls, fewer than the B2. System capacity comes from the number of stations.
It carries only three repeaters, half as many as the B2. On the B4 coverage is solved mainly with further stations.

⚑ atlantis note

Design the system top down, from the base station to the handsets

A Rove enquiry usually arrives as a handset count. A usable specification starts elsewhere, with the number of simultaneous calls at peak and the area to be covered. That determines the choice between the B2 and the B4 and the number of R8 repeaters. Only then are the Rove 30 or Rove 40 handsets added. The reverse order ends in a follow-up order and an unhappy customer.

Do not mix goods from different regions

European Rove base stations work in the 1880 to 1900 MHz band, while the US versions of the handsets and the repeater use 1920 to 1930 MHz. The handset auto configures to the band of the base station, but even so order the whole system in European codes with the #ABB suffix and do not top it up with goods from other regions.

The B2 has the adapter in the box, the B4 does not

A detail that is missing from project budgets more often than any other. The Rove B2 has the power adapter in the box, the B4 does not, it is PoE powered and the adapter is optional, code 85W97AA#ABB. So if the design calls for several B4 stations in places without PoE, add the adapters.

Who it suits

Recommended deployment
Recommended use	a DECT base station for multicell deployment of the Poly Rove system
Position in the portfolio	wireless DECT phones, the Poly Rove system, infrastructure part
How it differs from the other products in the range	against the B2 it is meant for a multicell system, it is PoE powered, it has no adapter in the box and it carries half as many repeaters

Suitable

A campus, a multistorey building, a large warehouse or a production hall where a large area has to be covered and dozens of calls run at once. A hospital, a hotel, a logistics centre.

Verify

How many calls will run at once in each zone. How many stations will be needed and whether PoE is available where they are mounted. How many R8 repeaters will fill in the coverage. Which PBX or cloud service the system will register to.

Consider another product

The Rove B2 for one floor or a smaller site, with the adapter in the box and a higher call capacity per station. The Rove R8 repeater if the base station is already deployed and only the coverage is missing.

The "Verify" and "Consider another product" cards come from the experience of the atlantis team.

What the base station serves

Handsets

Rove 30 and Rove 40

Handsets register to the base station and take their band from it. Up to 1,000 handsets across the system and up to 8 simultaneous calls per station.

Rove 30

Rove 40

up to 1,000 handsets

Coverage extension

Up to three R8 repeaters

A Rove R8 repeater extends the range where the station signal does not reach. It needs only a mains socket and supports encrypted daisy chaining.

up to 3× R8

up to 300 m outdoors

Deployment scale

Up to 254 stations per system

The system grows as stations are added, to 254 units, 1,000 handsets and 2,000 simultaneous calls. For one floor the B2 is enough.

up to 254 stations

2,000 calls

Platform for this order code: DECT, a Poly Rove base station for multicell deployment. SIP registration is handled by the station, not by the handset.

Connectivity, network and security

Connectivity and security of the Poly Rove B4
Wireless technology	DECT, the 1880 to 1900 MHz band for Europe and the Asia Pacific region
Deployment	multicell, up to 254 base stations per system
Range	up to 50 m indoors from one station, with repeaters up to 300 m outdoors depending on the environment
Network port	1× RJ-45, 10/100/1000BASE-TX
Power	PoE powered; the external 5 V 2 A adapter is optional and not in the box, code 85W97AA#ABB
Security	DECT end-to-end encryption, DECT security certified
Repeaters	up to three Poly Rove R8 repeaters per station
Operating temperature	−10 to 55 °C

Capacity, coverage and power

Capacity and coverage of the Poly Rove B4
Simultaneous calls	up to 8 per station and up to 2,000 across the system
Number of base stations	up to 254 in one multicell system
Number of handsets	up to 1,000 across the system
Coverage	determined by the number of deployed stations, the range of one station being up to 50 m indoors
Repeaters	up to three Rove R8 per station
Power	PoE; the 5 V 2 A adapter is optional and not in the box
Compatible handsets	Poly Rove 30 and Poly Rove 40
Operating temperature	−10 to 55 °C

In the box

Rove B4 base station
Ethernet cable
Desk stand
Quick start guide and safety information sheet

Not included

Handsets, Rove 30 code 84H76AA#ABB or Rove 40 code 84H77AA#ABB
Repeater Rove R8, code 84H79AA#ABB
Power adapter, optional code 85W97AA#ABB, the station expects PoE
Any PBX licence or service
Poly+ Partner service programme

Order with it

Poly Rove 40 handset with Bluetooth84H77AA#ABB

A rugged IP65 handset with Bluetooth 4.2 for a wireless headset. Battery, cradle and adapter are all in the box.

Poly Rove 30 handset84H76AA#ABB

The same durability and endurance as the Rove 40, without Bluetooth. A headset connects via the 3.5 mm jack.

Poly Rove R8 repeater84H79AA#ABB

Up to three per this station. It needs only a mains socket, not a data one.

Li-ion battery for Rove 30 and 4085W99AA

A second battery to swap in multishift operation.

Poly Rove power adapter85W97AA#ABB

A universal adapter for the Rove 30, 40, B2, B4 and R8. Required for this station everywhere PoE is not available.

Poly+ Partnerby model and term

Extended support with expedited replacement, ordered together with the device.

Variants and products in the range

Poly desk and wireless phones in our offering
Range	Type	What characterises it	Intended for
Poly Rove ◂ this product	DECT system	a base station, repeaters and rugged IP65 handsets	moving around a building, warehouse, production
Poly Edge E	IP desk phone	eight models from 2 to 14 keys, classic key based operation	ordinary and demanding office positions
Poly CCX	IP desk phone with touch	Android 12, touch display, Open SIP and Microsoft Teams versions	positions with touch operation
Poly Trio 8300	conference phone	SIP, Wi-Fi, Bluetooth, 3.7 m pickup	medium meeting room
Poly Trio C60	conference phone	SIP, Wi-Fi, Bluetooth, DECT, Teams version	larger meeting room

What to verify before ordering and deploying

Simultaneous calls in each zone: one station carries up to 8 calls, system capacity is up to 2,000
Number of stations and their placement: the system handles up to 254 stations, placement follows the floor plan and the wall materials
Repeaters: up to three R8 units on this station, each needs a mains socket
PoE where the stations are mounted: the station is PoE powered, where there is none add the 85W97AA#ABB adapter
PBX or service: what the system will register to and how many SIP accounts will be needed
Handsets: the Rove 30 or Rove 40, they are not in the base station box

The atlantis team helps with every point. From the coverage design and the choice of base station through connecting to the PBX to handset registration and user training.

Management and services

System management: configuration, handset registration and service profile assignment are done on the base station, not on the handset
Poly+ Partner: local support from an experienced certified team in Czech, by phone, chat, web and video call, priority device replacement where the manufacturer ships the replacement the next business day and covers the shipping, all under the terms of the programme and for its entire validity, so the care can continue after the warranty ends
atlantis deployment: coverage design, the choice of base station and the number of repeaters, connection to a PBX or cloud service, handset registration and user training

Warranty

Standard one-year HP Poly limited warranty. Extended support with expedited replacement is provided by the Poly+ Partner programme.

FAQ

How many handsets can I connect to this system?

Up to 1,000 handsets across the whole multicell system, which holds up to 254 base stations. Call capacity is up to 8 per station and up to 2,000 across the system.

How does it differ from the Rove B2?

The Rove B4 is meant for a multicell system of up to 254 stations and 1,000 handsets, the Rove B2 for one or two cells. A single B4 station handles up to 8 simultaneous calls against 10 on the B2, but the capacity of a B4 system is up to 2,000 calls. The B4 is PoE powered and has no adapter in the box, the B2 has one. The B4 takes three repeaters, the B2 six.

Is a power adapter in the box?

No. The Rove B4 is PoE powered and the box holds an Ethernet cable and a desk stand instead of an adapter. Where there is no PoE at the mounting point, order the 85W97AA#ABB adapter, an external universal 5 V 2 A supply.

What area does the system cover?

In a multicell system coverage is determined by the number of deployed stations. The range of one station is up to 50 metres indoors, and with R8 repeaters up to 300 metres outdoors depending on the environment. We design the station placement from the floor plan.

How many R8 repeaters can be connected?

Up to three Poly Rove R8 repeaters on one Rove B4 station. On the Rove B2 it is six. A repeater needs no data socket, a mains one is enough, and it supports encrypted daisy chaining.

Which DECT band does the station work in?

The 1880 to 1900 MHz band for Europe, Australia, the United Kingdom and the Asia Pacific region. The US versions of the handsets and the repeater use 1920 to 1930 MHz. Order the whole system in European codes with the #ABB suffix.
